Ceramic mining and concrete

Heavy sludge agitators

Operating in the ceramic industry, in mining, or in concrete processing often involves having to deal with the storage of slurry, ceramic slips and ceramic glaze: PRO-DO-MIX® can help professionals find the right equipment for any processing requirements.

Thanks to the use of industry-leading mechanical design processes and technologies, PRO-DO-MIX®, working side by side with industry experts including designers and engineers, has succeeded in replacing the old gate mixers with innovative vertical agitators capable of combining top-level performance, superior energy efficiency and a well balanced cost-efficiency.

We at PRO-DO-MIX® have created an entire dedicated product line for the ceramic, mining and concrete industries, specifically designed for continuous mixing of high viscosity fluids: come and find out about our SilverLine and all the available models and their technical specifications.

Technical range

  • Installed power: 1,5 ÷ 45 kW
  • Operation: geared motor, pneumatic or hydraulic drive
  • Mounting: IEC motor flange, square base plate, welded house bearing, DN flange PN10/16, ASME flange 150 / 300 lb
  • Bearing: with or without extra bearing
  • Shaft seal: radial seal (lip seal), packing seal, labyrinth seal, single mechanical seal, double mechanical seal
  • Shaft: solid bar, seamless pipe, Ø 20 ÷ 270 mm, for length >6 in more parts flanged
  • Impellers: size and type depend on the Customer’s process
  • Option: bottom support bearing to stabilize the shaft
  • Moc: carbon steel, SS304, SS316L, SAF2205, SAF2507, different lining
  • Typical installations

  • heavy slurry mixing and storage
  • ceramic slip preparation
  • ceramic glaze preparation
  • cement grout storage
  • solvent extraction
  • mud agitator
  • leaching tanks
  • precipitation tanks
  • mixing tanks
  • Mining slurry

    Mining slurry

    The slurry resulting from mining activities can reach a density of up [...]
    Preparation of zirconium-based ceramic

    Preparation of zirconium-based ceramic

    The preparation of zirconium-based ceramic products is very common in the ceramic [...]
